Line 6 POD X3 User Manual

50-02-0079
PCBA MAIN POD X3 TNG BEAN P10-1
Part Number Description Qty. Per Reference Designator(s)
03-82-0106
CAP ELEC 10uF 16V 20% SM 4/5.4/5.5 2 C88,C90
04-01-0100
INDUCTOR DRUM-CORE 10uH @ 2.52MHz 1.15A SM GS43 1 L31
04-01-0220
INDUCTOR CHOKE 220uH 0.38R\2.4A SM 1 L30
04-04-0001
FERRITE BEAD 3-TURN 600R@ 100MHz MATERIAL-61 RADIAL TH 2 L15,L24
06-20-0099
DIODE GEN PUR DUAL 70V 215mA 6nS SOT-23 SM BAV99-7-F 5 D12,D20,D21,D22,D35
06-23-0054
DIODE SCHOTTKY DUAL 30V 200mA 5nS SOT-23 SM BAT54S 6 D26,D27,D33,D34,D36,D55
06-32-0340
DIODE SCHOTTKY 3A 40V SMB SM B340B 8 D10,D15,D16,D17,D18,D19,D23,D54
06-32-4006
DIODE RECTIFIER 800V 1A SMA SM MRA4006T3G 2 D28,D29
06-34-0016
DIODE SWITCHING 75V 200mA 6nS SOT-23 SM BAS16LT1G 21 D9,D24,D25,D32,D37,D38,D39,D40,D41,D42,D43,D44,D45,D46,D47,D48,D49,D
50,D51,D52,D53
09-06-2955
TRANS POWER-MOSFET P-CHAN 60V 230mR NTP2955 TO-220 TH 1 Q2
09-10-4403
TRANS PNP SMALL-SIGNAL MBT4403SOT-23 SM 1 Q1
11-00-0003
CRYSTAL 24MHz 2-P LOW PROFILE METAL CAN TH AT49 1 Y1
11-01-2258
OSCILLATOR 22.5792MHz 3.3V W/3-S HCMOS OUT 4P HS-DIP8 1 Y3
11-01-2458
OSCILLATOR 24.576MHz 3.3V W/3-S HCMOS OUT 4P HS-DIP8 1 Y2
11-10-0033
INDUCTOR CHOKE 33uH 0.23R/.88ACR-54 SM 2 L26,L27
11-10-0501
FERRITE BEAD 500R @100mHZ 2.5A 1206 SM 2 L8,L12
11-10-2012
FERRITE BEAD 600R@100MHZ 300mA 0805 SM 21 L1,L2,L3,L4,L5,L7,L9,L10,L11,L13,L14,L17,L18,L19,L20,L25,L28,L32,L33,L34
11-33-0120
XFMR AUDIO DIGITAL X-MISSION 1:1 1 T1
12-00-7808
IC REG +8V 1A TO-220 TH LM7808 1 U17
12-02-0015
IC REG +15V 1.5AMP TO-220F TH NJM7815FA# 1 U27
12-02-7805
IC REG +5v 1.5 Amp TH 3 U5,U23,U28
12-52-1118
IC REG 1.8V LDO LINEAR 800mA SOT-223 SM LM1117MPX-1.8 1 U1
12-54-0074
IC OP-AMP TL074 SM 3 U6,U18,U19
12-54-0134
IC OP AMP - OPA134UA SM SO-8 1 U31
12-54-5538
IC OP-AMP DUAL LO NOISE NE5532AD8 SM SO-8 3 U29,U30,U34
12-64-4272
IC CONVERTER A/D CODEC 24-BIT/192 kHz STEREO CS4272 TSSOP-28 2 U24,U26
12-70-2717
IC CONVERTER DUAL STEP-DOWN DC-DC LM2717 TSSOP-24 SM 1 U11
15-64-0000
IC 74HCT00 QUAD 2 INPUT NAND SO-14 SM 1 U41
15-64-0014
IC 74HCT14 HEX INVERTER 6 SM 1 U22
15-64-0273
IC 74HCT273 FLIP-FLOP D-TYPE 8-BIT SO-20 SM 2 U20,U21
15-65-0002
IC 74LCX02 LOW VOLTAGE CMOS QUAD 2 INPUT NOR SO-14 SM 1 U10
15-65-0015
IC SN74LVC14A LOW VOLTAGE CMOSINV HEX SCHMITT TRIG. SOP14 SM 1 U40
15-68-2374
IC CONTROLLER PWM DC/DC CONVERTER NJM2374AE DMP-8 SM 1 U32
15-68-6801
IC CONTROLLER USB 2.0 w/8052 MCU CY7C68013A-56PVX SSOP-56 1 U3
15-70-0002
IC SDRAM 3.3V 64MB 1M x 16 x 4TSOP-54 SM 2 U9,U14
15-78-0256
IC EEPROM 256KBIT I2C 2.5V SERIAL 24LC256I SOIC8(.200) SM 1 U2
15-79-0088
IC MEMORY SECURE AT88SC153-00 -2.7 8S1 (SO-8) SM 1 U4 Non Programmed IC (requires ESN)

Line 6 POD X3 Specifications

General

Type	Multi-Effects Processor
Amp Models	78
Effects Models	98
Display	LCD
Technology	Digital
Inputs	1 x 1/4" Guitar, 1 x XLR Mic, 1 x 1/4" Aux
Outputs	1 x XLR
MIDI	In/Out
USB	Yes
Power Supply	9V AC adapter (included)
