Line 6 Relay G30 User Manual

1. Audio LED - Green LED = Audio Signal
2. Battery LED
•Blue LED = Full Charge
•Solid Red LED = Low Charge
•Flashing Red LED = Very Low Charge
3. Power - Slide switch to turn on/off transmitter.
4. Channel Select - Align transmitter and reciever channels.
5. Input
6. Battery Installation - Open the side door to access the battery
compartment. The inside of the battery compartment door indicates
the correct battery direction. For best results use only non-rechargeable
alkalinebatteries.
7. Power Supply - To turn on the receiver, plug the Line 6 DC-1 power
supplyintothereceiver’s9VDCinputjack.
1 2
3
8
4
4
+
75
6
11
9
10
12
13
Basic OperatiOn

Line 6 Relay G30 Specifications

General

Receiver type	-
Frequency range	10 - 20000 Hz
Audio output channels	- channels
Power output per channel (20-20KHz@8 Ohm)	- W
Speakers connectivity type	XLR / 1/4\
Ethernet LAN	No
Supported radio bands	Not supported
Display	LED
Product color	Black
