4. Connect your guitar or other audio source to Sonic Port. Sonic Port supports one input source at a
time.
• Using
Guitar In (mono): Connect a standard 1/4 inch guitar cable to the Sonic Port guitar
input, then plug the other end into your guitar.
• Using IN L/R: Connect a standard stereo 1/8 inch line cable to the Sonic Port IN L/R input, then
plug the other end into a line level audio output of your source equipment such as a keyboard,
mixer, or music player.
5. Connect a mono or stereo 1/4 inch cable to the Sonic Port OUT L/R output, then plug the other end
into a playback device such as a guitar amp, mixer or powered speakers to monitor your audio. If
desired, connect a pair of headphones or earbuds to the Sonic Port 1/8 inch Headphones Output
.
6. Launch the audio app of your choice, for example GarageBand
®
or Mobile POD. Sonic Port works
as an audio input or output source for any app that uses Core Audio.
