BASIC OPERATION
Remote Control Operation
The Smart LED Light Bulb can be controlled ON / OFF/ BRIGHT / DIM through
wireless signals from the Z-Wave remote controller or through a gateway via an
application on a smart phone, tablet, or PC.
Once the Smart LED Light Bulb has been added to the network,depending on
the functions supported by your controller, it can be assigned to a Group or
Scene and operate when the ALL ON or ALL OFF command is received from
the Controller. It can also be set in Association with another Z-Wave device to
perform a specifi c duty.
Manual Operation
The Smart LED Light Bulb can be manually operated using the wall switch while
keeping it on-line with the Z-Wave network.
To manually turn the Smart LED Light Bulb ON:
Flip the wall switch OFF then ON. Be sure the switch is ON when fi nished.
To manually turn the Smart LED Light Bulb OFF:
Flip the wall switch OFF then ON twice within two seconds. Be sure the switch
is ON when fi nished.
CONFIGURATION
The LB60Z-1 supports the Confi guration command. The LB60Z-1 can be
confi gured to operate slightly differently than how it works when you fi rst install
it. Using the Confi guration command you can confi gure the following:
Parameter 1: Dim Level Memory
By default, the LB60Z-1 bulb will go to full brightness when turned on. To have
the bulb turn on to the last dim level setting, set parameter 1 to 1.
• Parameter No: 1
• Length: 1 Byte
• Valid Values = 0 (default) or 1.
• When the value = 0, the bulb will be full brightness when turned on.
• When the value = 1, the bulb will turn on to the last dim level setting.
Z-Wave Plus Features
The LB60Z-1 contains a Z-Wave 500 Series Module that supports Z-Wave Plus
features. A Z-Wave certifi ed portable or stationary controller can communicate
with the Z-Wave 500 Series Module.
Depending on the capability of the controller or gateway software, the following
operations can be performed with the Smart LED Light Bulb. Refer to the
controller or gateway manual for details.
• Turn the bulb ON and OFF.
• Dim the bulb.
• Add (Include) or Delete (Exclude) the Smart LED Light Bulb.
• Assign the Smart LED Light Bulb to a specific Group/Scene and/or to include
the bulb as part of ALL ON or ALL OFF system commands.
• Over-the-air firmware update by the gateway or static controller.
• Lifeline function which automatically notifies the associated modules and the
network that a manually reset device is no longer in the network, thus, the
corresponding association becomes invalid.
INTEROPERABILITY WITH Z-WAVE DEVICES
A Z-Wave network can integrate devices of various classes of products, and
these devices can be made by different manufacturers. The LinearLinc Smart
LED Light Bulb has Z-Wave certifi cation which guarantees interoperability.
ASSOCIATION
The LB60Z-1 supports one Group with fi ve Nodes for lifeline communication.
Group 1 must be assigned the Node ID of the controller to which unsolicited
notifi cations from the LB60Z-1 will be sent. The Z-Wave controller should set this
association automatically after inclusion. You can associate up to fi ve Z-Wave
devices to Group 1. Lifeline association only supports the “manual reset” event.
For instructions on how to “set lifeline association” please refer to your wireless
controller instructions.
SPECIFICATIONS
Power Supply 120 VAC, 60 Hz
Brightness 750 lumens (Equivalent to 60 Watt
incandescent light bulb)
Power Consumption 9 Watts
Color Temperature 2700K
Bulb Lifetime 25,000 hour (equivalent 22.8 years based
on 3 hours/day)
Radio Frequency 908.4 MHz / 916 MHz
Wireless Range Up to 130 feet line of sight between the
Z-Wave Controller and/or the closest
Z-Wave Repeater
Normal Operating Temp 77°F (25°C)
Repeater Ye s
REGULATORY INFORMATION
The LB60Z-1 is certifi ed to comply with applicable FCC and IC rules and regulations governing RF and EMI emissions.
FCC ID: EF400126 IC #: 1078A-00126
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device
may not cause harmful interference, and (2) This device must accept any interference received, including interference
received that may cause undesired operation.
FCC Notice
This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of
the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential
installation.
This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance
with the instructions may cause harmful interference to radio communications. However, there is no guarantee that
interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or
television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to
correct the interference by one or more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver
• Connect the equipment into an outlet on a circuit different from that to which the receiver is connected
• Consult the dealer or an experienced radio/TV technician to help.
• Changes or modifications not expressly approved by the party responsible for compliance could void the user’s
authority to operate the equipment
IC Notice
This Class B digital apparatus complies with Canadian ICES-003
Cet appareil numérique de la classe B est conforme à la norme NMB-003 du Canada. Le présent appareil est conforme
aux CNR d’Industrie Canada applicables aux appareils radio exempts de licence. L’exploitation est autorisée aux deux
conditions suivantes : (1) l’appareil ne doit pas produire de brouillage, et (2) l’utilisateur de l’appareil doit accepter tout
brouillage radioélectrique subi, même si le brouillage est susceptible d’en compromettre le fonctionnement.
Cet appareil numérique de la classe B est conforme à la norme NMB-003 du Canada. Operation is subject to the
following two conditions: (1) this device may not cause interference, and (2) this device must accept any interference,
including interference that may cause undesired operation of the device.
WARRANTY
This Linear product is warranted against defects in material and workmanship for twelve (12) months. This warranty
extends only to wholesale customers who buy direct from Linear or through Linear’s normal distribution channels.
Linear does not warrant this product to consumers. Consumers should inquire from their selling dealer as to the
nature of the dealer’s warranty, if any. There are no obligations or liabilities on the part of Linear Corporation for
consequential damages arising out of or in connection with use or performance of this product or other indirect
damages with respect to loss of property, revenue, or profi t, or cost of removal, installation, or reinstallation.
All implied warranties, including implied warranties for merchantability and implied warranties for fi tness, are valid only
until Warranty Expiration Date as labeled on the product. This Linear LLC Warranty is in lieu of all other warranties
express or implied. All products returned for warranty service require a Return Product Authorization Number (RPA#).
Contact Linear Returns at 1-855-546-3279 for an RPA# and other important details.
IMPORTANT !!!
Linear radio controls provide a reliable communications link and fi ll an important need in portable wireless signaling.
However, there are some limitations which must be observed.
• For U.S. installations only: The radios are required to comply with FCC Rules and Regulations as Part 15 devices.
As such, they have limited transmitter power and therefore limited range.
• A receiver cannot respond to more than one transmitted signal at a time and may be blocked by radio signals that
occur on or near their operating frequencies, regardless of code settings.
• Changes or modifications to the device may void FCC compliance.
• Infrequently used radio links should be tested regularly to protect against undetected interference or fault.
• A general knowledge of radio and its vagaries should be gained prior to acting as a wholesale distributor or dealer,
and these facts should be communicated to the ultimate users.
USA & Canada (800) 421-1587 & (800) 392-0123
(760) 438-7000 - Toll Free FAX (800) 468-1340
www.linearcorp.com
