The
HDEXT1IR232 HDBasedT Lite Extender with
Bi-direconal IR & RS-232
boosts up your video/audio transmission
distance up to 60m (198) in HDTV 1080p with 48-bit color depth.
HDEXT1IR232 also supports the most advanced 3D video format
complaint with HDMI specificaon and therefore guarantees the
highest 3D video compability on the market. With only one cost
effecve Cat.5/5e/6 cable, users can readily extend HDTV sources from
DVD players, Blu-ray Disc player, PS3, PC, and any other kinds of
sources compliant with TMDS to distant display monitors including
HDMI or DVI enabled TV sets or LCD PC monitors. With the advanced
design for the latest HDMI technology, deep color video, DTS-HD or
Dolby TrueHD audio, and HDCP supports and compability are all
further insured. This flexibility makes HDCP compliant DVD players or
PS3 transmit utmost high quality video and audio with a greater
distance at the minimal cost, when integrang several components
apart. In addion, HDEXT1IR232 is also equipped with bi-direconal IR
pass-through path and RS-232 serial port control. These bonus features
allow users to boost IR control distance up to 60m (198 ) and makes IR
control possible through only single Cat.5/5e/6 cable including HDMI
signals. In addion, serial port offers the convenient path for interacve
applicaon, such as touch panels.
The HDEXT1IR232 includes two units: transming unit
HDEXT1IR232-TX and receiving unit HDEXT1IR232-RX. The transming
unit is used to capture the input HDMI / DVI signals with IR control
packets and carry the signals via one cost effecve Cat.5/5e/6 cable.
The receiving unit is responsible for equalizing the transmied HDMI
signal and reconstrucng IR signals. HDEXT1IR232 offers the most
convenient soluon for digital signage with long distance A/V
transmission path, and with 10G transmission width ready,
HDEXT1IR232 is ready for your next HDMI generaon and applicaons!
Support HDMI Deep Color & full 3D & 4K2K@30 (HDBaseT-Lite
technology)
Extend the transmission up to 60m (198) from the HDMI source at
Full HD 1080p 48-bit and 40m (130) at 4K2K@30
HDCP & EDID Bypass
CEC support
Auto equalizaon
Pure unaltered uncompressed 7.1ch digital HDMI over Cat.5/5e/6
cable transmission
DTS-HD Master Audio and Dolby TrueHD high bit rate audio support
Support full frequency IR signal from 20KHz to 60KHz
Bi-direconal IR path-through
Full Duplex RS-232 control up to 115,200 bps through connector
Wall mounng housing design for easy and robust installaon
1x HDEXT1IR232
[TX&RX]
2x 5V DC power supply
1x User Manual
1x IR blaster
1x IR receiver
INTRODUCTION SPECIFICATIONS
FEATURES
PACKAGE CONTENTS
The length depends on the characteriscs and quality of the cables.
Higher resoluons and longer transmission distances require low
skew cables (<25ns/100m) for best performance. Unshielded CAT6
with metal RJ45 connectors is recommended.
IR PASS-THROUGH
IR Extenders
CONNECTION DIAGRAM
PANEL DESCRIPTIONS
Transmitting unit ► HDEXT1IR232-TX[RX]
RS-232: Connect to host/device serial port
with a DSUB-9 male-male cable here
Dip Switch: Setup the RS-232 mode for serial
communication channel
LED: TX/RX link indicator
RJ45: Plug in a Cat-5/5e/6 cable that needs
to be linked to the TX or RX.
IR ReceiverIR Blaster
IR ReceiverIR Blaster
IR Sockets
IR BLASTER: plug in the IR blaster to emit all IR command signals
received from the IR receiver from the other end to control the devices
corresponding to the IR signals.
IR RECEIVER: plug in the IR receiver to receive all IR command signals
from the IR remote controls of the corresponding devices.
!
Incorrect placement of IR Blaster and Receiver may result in the
failure of the IR extenders. Please check carefully before plugging in
the IR extender to the respecve IR sockets. Warranty will not cover
the damage.
You can buy any IR extension cables in the market that are
compable to the definion of the IR sockets for the matrix if
necessary for replacement use. However, IR cables longer than 2m
(6-) may not work.
1. IR Signal
2. Grounding
1. IR Signal[20-60 kHz]
2. Grounding
3. Power
i
i
[Receiving unit]
