LinkAYL LK-MR53 Series User Manual

Operation Description
 Setting method of single channel receiver is as same as double channel receiver.
 Before setting multi channel transmitter, please choose the right channel which
you want to program.
 Maximum running time of motor is 5 minutes.
 UP/DOWN delay time of switch is 500ms.
 Matching Code
 Power the controller on.
 Keep pressing [STOP] on the controller for 5 seconds.
 Press [UP] on the remote within 15 seconds
 LED flashes 3 times and turns off.
 Codes are matched successfully.
 Clearing Single Code
 Power the controller on.
 Keep pressing [STOP] on the controller for 5 seconds.
 Press [DOWN] on the remote within 15 seconds
 LED flashes 3 times and turns off。
 Code is cleared successfully.
 Clearing All Codes
 Power the controller on.
 Keep pressing both of [STOP] and [DOWN] on the controller for 5 seconds.
 LED flashes 3 times and turns off.
 All the codes matching the channel will be deleted after this operation.
 Changing direction
 Power the controller on.
 Keep pressing both of [UP] and [DOWN] on the controller for 5 seconds.
 LED flashes 3 times and turns off.
 Directions changed successfully.
 Inching mode
 Power the controller on.
 Keep pressing both of [UP] and [STOP] on the controller for 5S.
 LED flashes 3 times and turns off. Setting is ok.
 Repeat the action, it turns to normal mode.
 It can work continuously when pressing the [UP] or [DOWN] for more than
1.5 seconds.
Installation Notes
 Please observe the following provisions in accord with standard of effective power.
 Do not use metal objects to touch or shade the receiver, avoid the interference of
receiving signals.
 Transmit distance: 50 meters without obstacle, 20 meters through wall.
 The installation distance between the receiver and ground, between the receiver
and the ceiling is more than 1.5 m, between two receivers is more than 0.2 m.
 The main power supply must be cut off before installing wiring.
 In order to prevent electrostatic interference, must ensure that the receiver is
effectively grounded.
 After the installation, ensure that the receiver and cable are not affected by tension.
Troubleshooting
No. Symptom Solution
1 LED flashes, receiver shut down.
1. Check the connection of wires.
2. Check the receiver setting.
2 LED on the transmitter is off or weak.
1. Make sure the right installation of
the battery.
2. Change the battery.
3
The transmitter and the receiver
work well, the motor does not work.
1. Check the wiring of motor.
2. Make sure the motor no failure.
