Specifications
Sampling frequencies
PCM :
44.1, 48, 88.2, 96, 176.4,
192, 352.8 kHz ; S/PDIF
– input limited to 192
kHz max.
Resolution PCM : 32bit
Resolution DSD : DSD64 (2.8224MHz)
and DSD128
(5.6448MHz) over DoP
protocol, DSD256 and
DSD512 over ASIO
native
Master clock jitter : 82 fs (femto seconds)
Frequency response : DC - 24kHz +0.1dB -
0.5dB
DC – 70kHz -3dB
@192kHz
Distortion and noise : <0.0003% 10Hz - 20kHz
@ 0dB
Dynamic range : 138dB
Crosstalk : 120dB @ 20kHz
Output level :
6V rms single ended
12V rms balanced
@ 0dB and “100”
Output impedance : 300 Ohm per phase
Line input impedance : 600 Ohm per phase !
Power consumption : 14W, < 0.5W turned off
Dimensions (H x W x D) : 75 x 432 x 290 mm
