LISICKI Z-178/1 User Manual

32
Z-178
1,65 m
Z-178/2
1,85 m
Z-178/1
1,35 m
Z-178/1
(60)
1,35 m
Z-178/1
(80)
1,35 m
Z-178/3
2,10 m
40 Widened washer M8 PN-M-82030 4 4 4 4 4 4
41 Washer 18 PN-78/M-82005 2 2 2 2 2 1
42 Spring washer 8,2-Fe/Zn9 PN-77/M-82008 4 4 4 4 4 4
43 Bolt M8x20-5.6-B-Fe/Zn8C PN-85/M-82105 4 4 4 4 4 4
44 Bolt M12x30-8.8-B-Fe/Zn8C PN-85/M-82105 2 2 2 2 2 2
45 Nut M16-8-B-Fe/Zn8C PN-86/M-82144 2 2 2 2 2 -
Nut M14-8-B-Fe/Zn8C PN-86/M-82144 2 - 2 2 2 -
Nut M16-8-B-Fe/Zn8C PN-86/M-82144 - 2 - - - 2
47 Nut M10-8-B-Fe/Zn8C PN-86/M-82144 8 8 8 8 8 8
48 Spring washer 10,2-Fe/Zn9 PN-77/M-82008 4 4 4 4 4 4
49 Spring washer 12,2-Fe/Zn9 PN-77/M-82008 2 2 2 2 2 2
50
Split pin S-Zn Ø5x28 PN-76/M-82001 3 3 3 3 3 1
52
Pin Ø18x45 5-178-020-821 1 1 1 1 1 -
53
Pin Ø16x40 5-178-020-822 1 1 1 1 1 -
54 Nut M8-6-B-Fe/Zn8C PN-86/M-82144 4 4 4 4 4 4
7103056CE007007 1 1 1 1 1 - Optional equipment
7143-066-CE-007-096 - - - - - 1 Optional equipment
5-178-020-760 1 - 1 1 1 -
5-178-020-760/2 - 1 - - - 1
57
Pin Ø30 5-178-020-823 - - - - - 1
58 Split cotter 5-178-020-289 1 1 1 1 1 1
59
Pin Ø30 with inner thread 5-178-020-824 - - - - - 1
Part number or standard
Remarks
Quantity
Item no.
in Fig.
Part name
Support
56
46
55
U-joint shaft
Table 3. continued.
