Z-178

1,65 m

Z-178/2

1,85 m

Z-178/1

1,35 m

Z-178/1

(60)

1,35 m

Z-178/1

(80)

1,35 m

Z-178/3

2,10 m

11 Chain, set 5-178-020-274 1 1 1 1 1 1

5-178-020-389 2 2 2 2 2 -

5-178-020-389/2 - - - - - 2

5-178-020-391 1 - 1 1 1 -

5-178-020-391/2 - 1 - - - -

5-178-020-391/3 - - - - - 1

14 Tab washer 5-178-020-424 1 1 1 1 1 1

16 Washer 5-178-020-480

18 Latch spring 5-178-020-526 1 1 1 1 1 -

20 Washer 17 PN-78/M-82005 2 2 2 2 2 -

Pin Ø22h9x55 5-178-020-826 2 2 - - - 1

Pin Ø22h9x50 5-178-020-826/1 - - 2 2 2 -

24 Spring retaining ring Z16 PN-81/M-85111 1 1 1 1 1 -

Bolt M12x85-8.8-B-Fe/Zn8C PN-85/M-82101 1 - 1 1 1 -

Bolt M14x1,5x100 5-178-020-827 - 1 - - - 1

Self-locking nut M12-8-B-Fe/Zn8c PN-86/M-82175 1 - 1 1 1 -

Self-locking nut M14x1,5-8-B-Fe/Zn8c PN-86/M-82175 - 1 - - - 1

Nut M20x1,5-0,6B PN-85/M-82153 1 1 1 1 1 -

Self-locking nut M20x1,5-8-B-Fe/Zn8c PN-86/M-82175 - - - - - 1

28 Washer 22,5 PN-63/M-82004 4 4 4 4 4 2

29 Washer 25,5 PN-63/M-82004 1 1 1 1 1 1

Split pin S-Zn Ø5x30 PN-76/M-82001 1 1 1 1 1 -

33 Spring pricker A11x50 5-178-031-045 1 1 1 1 1 1

Joint sleeve

as needed

Shackle

Remarks

Item no.

in Fig.

Part name

Part number or standard

Quantity

Table 4. continued.
