Parameter
Name
Description
Setting Range
d1-06
Middle Output
Frequency
When d1-01 ≦ E, parameters d1-02 to d1-11
can be used to monitor the V/F pattern.
When d1-01 = F, parameters d1-02 to d1-11 can
be used to create a V/F pattern.
Default: <1>
Min.: 0.0 Hz
Max.: Defined by d1-02
d1-07
Middle Output
Frequency Voltage
Default: <1>
Min.: 0.0 V
Max.: 255.0 V <3>
d1-08
Minimum Output
Frequency
Default: <1>
Min.: 0.0 Hz
Max.: Defined by d1-02
d1-09
Minimum Output
Frequency Voltage
Default: <1>
Min.: 0.0 V
Max.: 255.0 V <3>
d2: Motor Parameters
d2-00
Motor Rated
Current
Sets the motor rated current. This will be set
automatically during Auto-Tuning.
Default: o2-03 (A)
Min.: 10% of drive rated
current (A)
Max.: 200% of drive
rated current (A)
d2-01
Motor Rated Speed
Sets the motor rated speed. This will be set
automatically during Auto-Tuning.
Default: o2-03
Min.: 0.00 Hz
Max.: 20.00 Hz
d2-02
Motor No-Load
Current
Sets the motor no-load current. This will be set
automatically during Auto-Tuning.
Default: o2-03
Min.: 0.0 A
Max.: d2-00
d2-03
Number of Motor
Poles
Sets the number of motor poles. This will be set
automatically during Auto-Tuning.
Default: 4
Min.: 2
Max.: 48
d2-04
Motor Line-to-Line
Resistance
Sets the line-to-line resistance. This will be set
automatically during Auto-Tuning.
Default: o2-03
Min.: 0.000 Ω
Max.:65.00 Ω
d2-05
Motor Leakage
Inductance
Sets the voltage drop caused by the motor
leakage inductance relative to the motor rated
frequency and current. This will be set
automatically during Auto-Tuning.
Default: o2-03
Min.: 0.00 mH
Max.:650.0 mH
d2-06
Motor Rotor
Resistance
Sets the motor rotor resistance. This will be set
automatically during Auto-Tuning.
Default: o2-03
Min.: 0.000 Ω
Max.:65.00 Ω
d2-07
Motor Mutual
Inductance
Sets the motor mutual inductance. This will be
set automatically during Auto-Tuning.
Default: o2-03
Min.: 0.0 mH
Max.:6500 mH
