LiteOn EVO600043S3D7E20F Quick Start Guide

53
Parameter
Name
Description
Setting Range
65: DC Braking
69 : Drive Enabled
(Note) 0xx/1xx are anti-logic
E2: Multi-Function Digital Output
E2-00
Relay 1 Function
Selection
0 : During Run
1 : Zero Speed Holding
2 : Frequency (Speed) Agree
3 :User-Defined Frequency (Speed ) Agree
4 : Drive Ready
5 : Uv (Undervoltage) Detection
6 : During Baseblock
8 : Frequency Command Source
9 : Frequency Command Loss
10: Run Command Source
11 : Fault
12 : Communication Mode
13 : Alarm
14 : Fault Restart
15 : Timer Outpu
16 : Frequency (FOUT) Detection 1
17 : Frequency (FOUT) Detection 2
18: Overvoltage/ Undervoltage Detection 1
(normal open)
20 : Retain
22 : During Reverse
23: Motor 1/ 2 Selection
24: During Regeneration
25 : During Restart
26 : Motor Overload Pre-Alarm (oL1)
27 : Drive Overheat Pre-Alarm (oH)
28 : Retain
35: During Frequency Output
36: Drive Enabled
37: Watt Hour Pulse Output
38 : Local/Remote Mode
39 : During Speed Search
40 :PID Feedback Low
41 :PID Feedback High
44 : During Fast Stop
47 : Retain
48 : Retain
Default: 0
Range: 0 to 49 / 100
to 149
