LiteOn WB116A - CERTIFICATION AND SILKSCREEN; REGULATORY CERTIFICATIONS; SILKSCREEN INFORMATION

WB116A Page 4/10 2015/10/15
1.5 CERTIFICATION
Country Regulatory ApprovalID Remarks
UnitedStates FCCPart15C PPQ‐WB116A FCCID:PPQ‐WB116A
Canada RSS‐247 4491A‐WB116A IC:4491A‐WB116A
Europe
EN300328v1.9.1
EN301489‐1/ ‐17
EN60950
EN62311
CElogo+NBnumber

Japan TELEC 
Taiwan NCC 
Russia FAC 
China SRRC 
UAE TRA 
Argentina CNC 
1.6 SILKSCREENINFORMATION
TOPSide Design Marking Description

Lead‐Free MinHeight3mm

Halogen‐Free MinHeight3mm


PWBMaterial FR‐4
BottomSide 

BoardNumber SpecifythePWB
Boardpositionofthe
workarea.

ULDirectSupport

ULRecognized
Component
E220370(PIOTEK)
E85792(APCB)
ULIdentification
Thesethreemarks
shouldbelocatedin
thesamearea.
MinimumMarkHeight
is1.8mm.
MinimumTextHeight
is1.2mm.
WB116A Modelname MinimumTextHeightis
1.2mm.
PPQ‐WB116A FCCID MinimumTextHeightis
1.2mm.
4491A‐WB116A ICNumber MinimumTextHeightis
1.2mm.

CEMarkandNB
Number
MinimumTextHeightis
3mm.

NCCIDandLogo


ChinaCMIITID

