Parts list for 1/2 Ton, 1 Ton, 1½ Ton, 2 Ton, 3 Ton, and 5 Ton Models
Pinion Shaft 1 GHH5001 JHH5001 KHH5001 LHH5001 NHH5001 KHH5001
Pinion Gear 2, 3 GHH5003T JHH5003T KHH5003T LHH5003T NHH5003T KHH5003T
(Set of 2)
Load Gear 4 GHH5004 JHH5004 KHH5004 LHH5004 NHH5004 KHH5004
Load Sheave 8 GHE5008 JHE5008 KHE5008 LHE5008 NHH5008 KHH5008T
Hand Chain 7 GHH5009J GHH5009J GHH5009J GHH5009J GHH5009J GHH5009J
(Per Foot)
Load Chain 9 GHH5009T JHH5009T KHH5009T LHH5009T NHH5009T KHH5009T
(Per Foot)
Pawl Kit 10, 12, 66 GHH5099 JHH5099 KHH5099 LHH5099 NHH5099 KHH5099
Disc Hub 13 GHH5013 JHH5013 KHH5013 LHH5013 LHH5013 KHH5013
Friction Disc 14 GHH5014 JHH5014 KHH5014 LHH5014 LHH5014 KHH5014
(Set of 2)
Ratchet 15 GHH5015 JHH5015 KHH5015 LHH5015 LHH5015 KHH5015
Handwheel 28 GHH5028 JHH5028 KHH5028 LHH5028 NHH5028 KHH5028
Cover
Top Hook 32 w/74 GHH5032T JHH5032T KHH5032T LHH5032T NHH5032T PHH5032T
Bottom Hook 47, 48 w/74 GHH5047U JHH5047U KHH5047U LHH5047U NHH5047U PHH5047U
Chain Fastening 48 GHH5048U JHH5048U KHH5048U LHH5048U NHH5048U PHH5048U
Bolt
Hardware 50, 51, 52 GHH5586 JHH5586 KHH5586 LHH5586 NHH5586 KHH5586
Repair Kit 53, 54, 55
Per Hoist 56, 65, 84
Bearing for 67 GHH5067 GHH5067 KHH5067 LHH5067 TR132713NR KHH5067
Pinion (Set of 4)
Bearing for 68 GHE5005 JHE5005 KHE5005 LHE5005 TR506213NR TR364710NR
Load Sheave (Set of 2)
Latch Kit 74 GHH5074U JHH5074U KHH5074U KHH5074U NHH5074U PHH5074U
Chain Guide 16 (2), 18, GHH161820 JHH161820 KHH161820 LHH161820 NHH161820 KHH161820
Kit 20
Gear Side 22 w/o 67, GHH5022 JHH5022 KHH5022 LHH5022 NHH5022 KHH5022
Plate 68
Wheel Side 24 w/o 68 GHE5024T JHE5024T KHH5024T LHE5024T NHE5024T KHH5024T
Plate
Handwheel 25 GHH5025 JHH5025 KHH5025 LHH5025 NHH5025 KHH5025
Gear Cover 27 w/o 67, GHH5027 JHH5027 KHH5027 LHH5027 NHH5027 KHH5027
79
Yoke Pin 33 RH4010033 RH4010033 RH4015033 RH4020033 RH4030033 RH4015033
Decal 79 647432401 647432402 647432403 647432404 647432405 647432406
Idle Sheave 36 - - - - - PHH5042
Assembly
When ordering spare parts, be sure to state part number, capacity, model number and quantities, referring to the
above list.
Consists of 1/2 Ton 1 Ton 1½ Ton 2 Ton 3 Ton 5 Ton
Description Index No. Part No. Part No. Part No. Part No. Part No. Part No.
Contact your nearest Little Mule Service Center for
parts and service. For a complete list, see pages 8 and 9.
Please have the hoist model number, serial number, and
part number with description available for reference.
