9
VIDEO GAME
CONTROLLER
SAMPLE CIRCUIT
MEET THE BIT
The button Bit is a classic:
big, round, and springy for
comfortable pressing! Push
it to turn something on and
release it to turn it o.
The button is like a door.
When you press it, the door
opens, letting the signal
pass through the Bit and on
to the next Bits in the circuit.
The button is a momentary
switch, you must continue
to press it for the signal to
flow. When you release
the button, the door closes,
stopping the signal from
passing on to other Bits.
HOW IT WORKS SAMPLE CIRCUIT
i3 BUTTON
p1 POWER
i3 BUTTON
o9 BARGRAPH
GAME SHOW
BUZZER
ELEVATOR
BUTTON
REAL WORLD ANALOGIES
