14
MEET THE BIT
w1 WIRE
The wire Bit has a flexible wire running between its two
bitSnaps. This allows you to place your Bits farther apart, turn
corners, and make connections that can twist, turn, and spin.
The wire doesn’t change the
signal in any way – it just
carries it over from one Bit
to another.
EXTENSION CORD POWER LINES STRING OF LIGHTS
p1 POWER
w1 WIRE
o3 RGB LED
MINI-CHALLENGE
Can you invent a circuit that uses the wire to shine the RGB
LED on the light sensor?
REAL WORLD ANALOGIES
SAMPLE CIRCUIT HOW IT WORKS
