MEET THE BIT
o11 SERVO
The servo is a motor that can swing back and forth or be
turned to a speci c position.
There are a few accessories you can use with the servo (like
the mechanical arm). You can nd out how to use those on
pages 26 and 27.
The servo has two modes. In
TURN mode, the input from
other Bits determines the
position of the hub – try
using a dimmer to set the
angle you want. In SWING
mode, the servo will move
back and forth on its own like
a pair of windshield wipers
– the input signal controls
the speed of the swing.
The servo's range of motion
is about 110 degrees.
TRUCK CRANE ROBOT
p1 POWER
i5 SLIDE DIMMER
MINI-CHALLENGE
Can you invent something that uses the servo to clean up
your desk?
WINDSHIELD WIPERS
o11 SERVO
MODE:
turn or swing
REAL WORLD ANALOGIES
SAMPLE CIRCUIT HOW IT WORKS
b
l
e
e
p
b
l
o
r
p
Attach the servo
hub. See pg 26.
