p1 POWER sends a signal through the circuit.
The w1 WIRE receives the signal from the power and
sends it along to the slide dimmer.
The i5 SLIDE DIMMER controls how much power goes to
the motors.
The rst o25 DC MOTOR uses the signal from the slide
dimmer to determine its speed. It then passes this signal onto
the second motor.
The second o25 DC MOTOR reads the signal from the rst
motor and also uses it to determine its speed.
Control the direction your car drives by
flipping the mode switches. Because the
motors face opposite directions, they
need to be set in opposite spin modes to
drive in one direction. Setting the motors
to the same direction mode will create a
car that spins around in circles.
The slide dimmer is like the gas pedal for your car.
As you slide it up, more power goes to your motors.
The wire gives you more flexibility in how
you position your Bits on the board.
o25 DC MOTOR
i5 SLIDE DIMMER
w1 WIRE
HOW IT WORKS
