USE A RUBBER BAND OR
MASKING TAPE TO KEEP
THE BATTERY IN PLACE.
PRESS SERVO INTO THE SERVO MOUNT AND SCREW IN.
2
PRESS THE SERVO MOUNT ONTO THE MOUNTING BOARD AND ADJUST
SERVO MODE.
4
PRESS YOUR CIRCUIT ONTO THE MOUNTING BOARD. TURN POWER ON.
3 5
USE PHILLIPS HEAD
SCREWDRIVER.
JUST ONE
SCREW NEEDED.
i12 temp.
sensor:
Fahrenheit
mode
i13 light
sensor:
light mode
o11 servo:
swing mode
i12 temp.
sensor:
celsius
mode
i13 light
sensor:
dark mode
o11 servo:
turn mode
MODE:
TURN
POWER:
ON
