MAIN ORGANS
A–Accumulator batteries: supply power to the motors of the blade and control the wheels.
B–Power Supply Unit: used to recharge or keep the batteries charged (A).
C–Electronic card: controls the automatic functions of the robot.
D–Control keyboard: used to set and display the operating modes of the robot.
E–Cutting blade: mows the lawn.
F–Electric motor: operates the cutting blade (E).
G–Electric motor: one operates the right wheel transmission unit, while the other operates the
left wheel.
H–Sensors: used to recognise the characteristics of the ground on which the robot is
operating.
A
B
F
G
C
E
D
H
H
