3.0 PRINCIPLE PARTS
Item No
Description of item
SHW35-245
SHW46-325
SHW61-325
SHW86-410
SHW116-410
SHW146-410
1.
AIR PRESSURE SWITCH
PRS20016
PRS20017
PRS20001
PRS20002
PRS20022
2.
BURNER C/W GASKET
BNR30019
BNR3426
BNR3427
BNR3428
BNR3429
3.
BURNER CONTROL
RLY40116
RLY40117
RLY40118
RLY40117
4.
BURNER DOOR GASKET - ROPE
GKT2452
5.
BURNER DOOR GASKET - RUBBER
GKT2455
6.
BURNER DOOR INSULATION
FIB2291
CLEAN OUT DOOR GASKET
GKT2101 NOT SHOWN ON DRAWING
7.
HEAT EXCHANGER REAR WALL INSULATION
FIB2167
8.
CONDENSATE TRAP
MSC20260
FLAME SENSE PROBE CABLE
WRE2211 NOT SHOWN ON DRAWING
9.
FLAME SENSE PROBE C/W GASKET
PLT3022
10.
DISPLAY PCB
RLY20120
11.
FLUE TEMPERATURE SENSOR GROMMET
N/A
MSC2200
12.
FAN ASSEMBLY
FAN2050
FAN2051
FAN2052
FAN2053
FAN2054
FAN2055
13.
FAN GASKET
GKT2456
GKT2436
GKT2456
GKT2436
-
14.
FLUE TEMPERATURE SENSOR
TST20007
TST30011
15.
GAS VALVE ASSEMBLY
VAL30071
VAL30072
VAL30073
VAL30074
VAL30075
VAL30076
16.
IGNITION CABLE
WRE2209
17.
IGNITION ELECTRODE C/W GASKET
PLT3021
18.
INLET TEMPERATURE SENSOR
TST20037
19.
OUTLET TEMPERATURE SENSOR/HIGH LIMIT
TST20038
20.
STEP DOWN POWER TRANSFORMER
LL100170179
21.
PUMP
PUM20081
PUM20082
PUM20083
22.
PUMP RELAY
RLY2610
23.
VENTURI GASKET
GKT2443
GKT2444
24.
MAGNESIUM ANODE
WTR2500
25.
HEAT EXCHANGER C/W GASKETS/FITTINGS
RECOMMEND LOCHINVAR FIT THIS ITEM
LL200030P
LL200031P
LL200032P
LL200033P
LL200034P
LL200035P
26.
LOW VOLTAGE CONNECTION BOARD
LL100167623
27.
AIR SHROUD GASKET
N/A
GKT2080
PRINCIPLE PARTS-USE IN CONJUNCTION WITH 3.1.2
