LOGSMITH BM11126 - Parts List and Diagrams; Parts List

Page 14
Part Description Qty
1 Wheel 4
2 Hex Nut M20 4
3a Left Wheel Frame 1
4 Clamp 1 1
5 Hex Nut M12 6
6 Hex Bolt M20×100 4
7a Right Wheel Frame 1
8 Hex Bolt M12×80 5
9 Hex Nut M12 6
10 Clamp 2 1
11 Hex Bolt M8×20 9
12 Hex Bolt M10×25 21
13 Hex Bolt M12×65 3
14 Tension Handle 1
15 Flat Washer 12 2
16 Hex Bolt M12×145 1
17 Hanging Plate 1
18 Hex Bolt M8×16 5
19 Right Clamp 1
20 Round Post 1
21 Lumber Thickness Scale 1
22 Hex Bolt M8×25 12
23 Top Frame 1
24 Flat Washer 8 9
25 Hex Nut M8 36
26 Taper Pin B6×40 2
27 Elastic Pin 5×20 1
28 Round Nut M14×1.5 2
29 Height Adjustment Arm 1
30 Height Adjustment Handle 1
31 Hex Bolt M12×65 3
32 Hex Nut M12 6
33 Guide Screw Base 1
34 External Tube 1
35 Pulley 5
36 Bolt M12×20 3
37 Snap Ring 12 3
38 Washer 3
39 Internal Tube 1
40 Hex Bolt M12×70 1
41 Washer 1
42 Flat Washer 2
43 Hex Nut M12 1
44 Bolt M10×45 2
45 Water Tank Tray 1
46 Cable Anchor Bolt 2
47 Hex Nut M10 4
48 Square Post 1
49 Hex Bolt M12×65 2
50 Blade Guard 1
51 Hex Bolt M12×45 1
Part Description Qty
52 Hex Nut M12 4
53 Hex Bolt M12×100 1
54 Left Lock Handle 1
55 Hex Bolt M8×45 6
56 Support Tube 1
57 Beam 1
58 Hex Bolt M12×80 2
59 Right Lock Handle 1
60 Hex Bolt M10×25 2
61 Elastic Washer 10 2
62 Flat Washer 10 2
63 Snap Ring 62 2
64 Bearing 6305 RZ 4
65 V- Belt B1900 1
66 Bandwheel 2
67 Clutch 1
68 Pin 1
69 Blade 1
70 Bolt M8×45 4
71 Fixed Block 4
72 Blade Guide 2
73 Blade Guide Shaft 2
74 Short Bandwheel Axle 1
75 Long Bandwheel Axle 1
76 V- Belt B1422 1
77 Hex Flange Bolt M10×25 28
78 Track 1 2
79 End Stop 4
80a End Support 2
81a Middle Support 2
82 Log Support 2
83 Rod Support 2
84 Hex Flange Nut M10 32
85 Round Tube 1
86a Rocker Tube Sleeve 1
87 Log Support T-Handle
M10x1.5x30 5
88 Rocker Tube 1
89 Log Clamp 1
90a Center Support 1
91 Short Log Support 2
92 Track 2 2
93 Throttle Control 1
94 Pushing Handle 1
95 Water Tank 1
96 Switch 1
97 Water Tube 1
98 Spring Washer 10 2
99 Hex Nut M10 4
100 Blade Roller Bearing 2
101 Top Frame Brace 1
