Bolt to secure engine bracket and transmission box 35~40
Bolt to secure reduction box cover 25~30
Bolt to secure damping lever fixing seat 50~60
Bolt to connect transmission box and reduction box 25~30
Bolt to secure engine bracket and engine 25~30
2. Check whether handles of operating system, namely the handles for accelerator, clutch, gear shift, and
reverse shift can work freely, and whether any of them cannot reach any required position, if so, check to repair
it.
3. Put the shift lever of the transmission box in the neutral position.
4. Filling of engine oil.
Put the engine on a horizontal place.
1) Loosen out the dip stick of the engine, and wipe it off (see Figure 5).
2) Put the dip stick into the oil filler hole (don’t engage the thread)
3) Take out the dip stick to check oil level; if the oil trace is between the upper and lower marks of the oil
stick, the oil level is acceptable.
4) The SAE15W-40 engine oil is the recommended general-purpose lubricant, and it is applicable to a
common ambient temperature (see Table 1).
5) Put the whole machine in a horizontal position. Take off the oil plug and add in about 2 liter of
SAE15W-40 engine oil to the transmission box. The normal oil level shall be at the middle of the oil
window (see Figure 6).
