MUDGUARDS
The 765 frame is designed for standard 4mm fender
stays, with small grub screws to secure them in
place. A dedicated Stronglight model with double
brackets attaches to the M4 lateral threads instead
of the pre-assembled M4 grub screws.
To secure the fender, two M5 inserts are located
behind the seat tube and behind the bottom bracket,
between the two chainstays. Finally, the use of a
bridge is necessary, particularly if you do not wish
to use the dedicated model.
If your standard mudguard only has one rear
bracket, the bridge must be added to reinforce the
setup. Note that this will stiffen the 2 seatstays and
limit their vibration-ltering function.
Similarly, the fork has 4mm slots on the rear of the
dropouts, and an M5 insert under the crown for
standard fender assembly.
1 / ASSEMBLY
1413
