Loop-O9500 SDH/SONET IMAP
SDH/SONET-MSTP
2
Table 1: Loop-O9500R Tributary Modules
Tributary Type
Plug-in Interface Cards
Maximum Capacity
For STM-1/4 (OC-3/12)
aggregate cross connect module
For STM-1/4/16 (OC-3/12/48)
aggregate cross connect module
on CHAA Chassis
High-Speed
(High Density)
Access Tributary
Modules
(HS)
STM-4 (OC-12) tributaries
1 MSP 1 + 1
2 MSP 1+1 or
2 Sub-ring SNCP or
4 STM-4 without protection
STM-1 (OC-3) tributaries
3 MSP 1 + 1 or
3 Sub-ring SNCP or
6 STM-1 without protection
4 MSP 1+1 or
4 Sub-ring SNCP or
8 STM-1 without protection
63 port E1/T1 tributaries
252 E1/T1 without protection, or 126
E1/T1 with 1+1 card protection
252 E1/T1 without protection, or
126 E1/T1 with 1+1 card protection
32 port E1/T1 tributaries
16 port E1/T1 tributaries
3 port E3/T3 tributaries
12 E3/T3 without protection, or 6
E3/T3 with 1+1 card protection
12 E3/T3 without protection, or
6 E3/T3 with 1+1 card protection
8FE+1GbE EoS card with/ without
built-in L2 switch
32 FE + 4GbE
32 FE + 4GbE
4GbE EoS card with L2 switch *
--
8 GbE
7 port FOM tributaries
28 FOM without protection, or 14
FOM with protection
28 FOM without protection, or
14 FOM with protection
Low-Speed Access
Tributary Modules
(LS)
Low Speed Single-Slot Cards
8-port Bridge/Router
48-port Bridge/Router
4-channel E1/T1
24-channel E1/T1
3-channel E1/T1
18-channel E1/T1 (DS0 SNCP Protection)
2-channel G.SHDSL (2 pairs)
without line power
12-channel G.SHDSL (2 pairs) without line power
4-channel G.SHDSL (1 pairs)
without line power
24-channel G.SHDSL (1 pairs) without line power
8-channel G.703 card at 64 Kbps
data rate
48-channel G.703 card at 64 Kbps data rate
1 or 4 channel C37.94
(low speed optical)
6 or 24 channel C37.94 (low speed optical)
8-channel RS232/V.24
48-channel RS232/V.24
8-channel Dry Contact I/O
48-channel Dry Contact I/O
8-channel Dry Contact I/O type B
48-channel Dry Contact I/O type B
8-channel 2W/4W E&M
48-channel 2W/4W E&M
12-channel FXS
72-channel FXS
12-channel FXO
72-channel FXO
Conference card
Conference card
12-channel Magneto
72-channel Magneto
TDMoE
TDMoE
8-channel Data Bridge
48-channel Data Bridge
8-channel UDTEA
48-channel UDTEA
1 port FOM (1FOMB)
6-port FOM
8-channel OCUDPA
48-channel OCUDPA
6-channel UDTEA*
36-channel UDTEA
Low Speed Dual-Slot Cards
6-channel V.35
18-channel V.35
6-channel V.36
18-channel V.36
6-channel X.21/V.11
18-channel X.21/V.11
6-channel EIA530/RS449
18-channel EIA530/RS449
24-channel FXS
72-channel FXS
24-channel FXO
72-channel FXO
*Future Option
Notes: Single-Slot Cards plug into singles slots; Dual-Slot Cards plug into two adjacent single slots
