Lortone NS8 - Parts List

LORTONE, inc • 12130 Cyrus Way, Mukilteo, WA 98275 U.S.A
Phone: 425-493-1600 • www.lortone.com
01/12
Page 3
Copyright © 2010 Lortone, Inc
PARTS LIST
Item # Description
040-030 Front Casting
040-031 Rear Casting
044-003 Arbor Shaft (NS8)
044-005 Arbor Shaft (NS8 Long Shaft)
101-023 3” x 3/4” Flange
105-008 1” Aluminum Spacer (not shown)
200-006 Ball Bearing w/ set screw
206-032 Retaining Ring
210-032 Drive Belt 4L280
211-092 3-Step Pulley
240-069 Bearing Isolator
481-026 Right Hand Arbor Nut, 3/4” x 16
481-046 Left Hand Arbor Nut, 3/4” x 16
040-030
040-031
240-069
240-069
481-046
481-026
101-023
101-023
206-023
206-023
200-006
200-006
211-092
210-032
044-003
044-005
