MAINTENANCE MANUAL OF ENGINE
94
2.2 Installing the intake pipe
1. Install the gasket A.
A-Intake pipe gasket
Attention: Prior to installation, replace it with a new
one.
2. Install the intake pipe A, and tighten it.
A-Intake pipe assembly
A
A
