MAINTENANCE MANUAL OF ENGINE
105
5. Dismantling/installing the flywheel parts
5.1 Dismantling the flywheel parts
1. Dismantle the bolt A and lockplate B.
A-Flywheel bolt
B-Lockplate
2. Remove the flywheel part A.
A-Flywheel part
Pay attention to personal safety.
3. Dismantle the bolt A, and remove the flywheel
cover B.
A-Set bolt
B-Flywheel cover
A
B
A
A
B
