MAINTENANCE MANUAL OF ENGINE
106
5.2 Installing the flywheel parts
Attention
During installation of the flywheel cover, first apply
clean lubricating oil at rear end of the crankshaft.
A-Rear end of the crankshaft
1. Install the dowel pin A, and install the gasket B.
A-Dowel pin
B-Flywheel cover gasket
Attention: During installation, replace the gasket
with a new one.
2. Install the flywheel cover A, and install and fas-
ten the bolt B.
A-Flywheel cover
B-Bolt
Attention: Check the rear oil seal on the flywheel
cover, and if damaged, must replace it.
A
A
B
B
A
