MAINTENANCE MANUAL OF ENGINE
107
3. Install the flywheel A, install the lockplate B and
bolt C.
A-Flywheel
B-Lockplate
C-Bolt
Attention: Prior to installation of the flywheel, in-
spect whether the dowel pin at the end of the
crankshaft is lost.
4. Fasten the set bolt A for the flywheel.
A- Bolt
Attention: After installation, turn the flywheel, and
inspect whether it rotates flexibly and is jammed.
Tightening torque of the flywheel bolt--50-60N.m
B
A
C
A
