MAINTENANCE MANUAL OF ENGINE
23
3. Dismantling the valve mechanism
3.1 Dismantling the cylinder head cover
1. Dismantle the nut (A) and gasket set (B) from the
cylinder head cover (C). Loosen the cylinder head
cover.
A-Nut, cylinder head cover
B-Gasket set
C-Cylinder head cover
2. Dismantle the cylinder head cover (A).
A-Cylinder head cover
A
B
A
C
