MAINTENANCE MANU
AL OF ENGINE
42
4.9 Installing the c
ylinder head co
ver
First
check
the
gasket
of
cylinder
head
cover
for
damage. I
f any
, replace it with a new on
e.
1. Instal
l the gasket and cy
l
inder head
cover
.
A-Gasket of cy
linder head cover
B-Cyl
inder head cover
2.
T
ighten
the
bolts
(A)
fo
r
fixi
ng
cy
linder
head
cover
.
A- Bolt
A
B
A
47
49
