MAINTENANCE MANUAL OF ENGINE
46
7. Dismantle the main bearing cap bolt A succes-
sively.
A-Main bearing cap bolt
8. Dismantle the main bearing cap A.
A-Main bearing cap
9. Dismantle main bearing cap A and main bearing
shell B, which shall be placed neatly.
A-Main bearing cap
B-Main bearing shell
Attention:
Dismantle the main bearing cap and main bearing
shell and mark the diesel engine in the sequence of
1, 2, 3, 4 from front to back. It shall be placed neat-
ly in successively without bump so that it will be
installed in sequence for assembly, or it will influ-
ence the performance of diesel engine.
A
A
A
B
