MAINTENANCE MANUAL OF ENGINE
74
4.4. Installing the fan
1. Install alternator components (See Section 3,
Chapter 5 of this Part).
2. Install fan A and fasten the bolt.
A-Fan
3. Install belt A
A-Belt
Belt tension ---98N
A
A
