MAINTENANCE MANUAL OF ENGINE
76
3. Dismantling/installing the oil pan parts
3.1 Dismantling the oil pan parts
1. Empty the oil, and overturn the engine. Disman-
tle the set bolts A of the oil pan part.
A- Bolt
2. Dismantle the oil pan part A
A-Oil pan part
Attention: Pay attention to personal safety during
dismantling because the oil pan is heavy.
A
A
