MAINTENANCE MANU
AL OF ENGINE
77
3.2 Installing the
oil pan pa
rts
1. Instal
l the oil pan gasket
A
A-Oil pan gask
et
Attention
Install
a new oil pan gasket.
2.
Install
the
oil
pump
parts
(see
Section
4.2
in
this
chapter)
3. Instal
l the oil pan.
A-Oil pan
4. T
ighten the set b
olts
A
in sequence
.
A- Bolt
A
A
A
82
84
