MAINTENANCE MANUAL OF ENGINE
78
4. Dismantling/installing the oil pump parts
4.1 Dismantling the oil pump parts
1. Dismantle the set bolts of the oil pump.
A- Bolt
2. Dismantle the oil pump parts A.
A-Oil pump part
A
A
