MAINTENANCE MANUAL OF ENGINE
84
5. Dismantling/installing the starter
5.1 Dismantling the starter
1. Dismantle the starter bolt A
A-Set bolt
B-Starter assembly
Attention: Hold the starter by hands during disman-
tling, and pay attention to personal safety.
5.2 Installing the starter
1. Install the starter and tighten the bolt B.
A-Starter assembly
B-Bolt
A
B
B
A
