Lowrance SonarHub - Power; Power controlled by External Switch; Power controlled by Multi-Function Display; Wiring Examples

WIFI-1
TRANSDUCER1 TRANSDUCER2
NET-3NET-1POWER
12V/24V 3A
NET-2
TRANSDUCER1 TRANSDUCER2
NET-3NET-1POWER
12V/24V 3A
NET-2
TT
Power
Connectors and LEDs
Wiring examples
TRANSDUCER1 TRANSDUCER2
NET-3NET-1POWER
12V/24V 3A
NET-2
TRANSDUCER1 TRANSDUCER2
NET-3NET-1POWER
12V/24V 3A
NET-2
Switch
12 / 24 V DC
+
_
Red
Black
Yellow
Blue
(n/c)
Blue
(n/c)
Blue
(n/c)
Red
Black
Yellow Red
Black
Yellow
+
_
Power
Control bus
To Multi-Function
Display
12 / 24 V DC
1
2
3 4
TRANSDUCER1 TRANSDUCER2
NET-3NET-1POWER
12V/24V 3A
NET-2
ID CONNECTORS LEDs
1 Ethernet
OFF No connection
ON/FLASHING - Green Connected and ok
2 Power
OFF No power
ON - Red System starting
ON - Green System operating
FLASHING Red/Green Software error - restart unit
3
CHIRP / Broadband
transducer
OFF Sounder not operating
FLASHING (every second) - Green Searching for bottom signal
ON
Operational system with
bottom signal detected
4
Structure Scan HD
transducer,
Spotlight
transducer
OFF Sounder not operating
FLASHING (every second) - Green Searching for bottom signal
ON
Operational system with
bottom signal detected
Power controlled by External Switch Power controlled by Multi-Function Display
Views on the MFD:
CHIRP
or
StructureScan plus single
frequency 83 kHz
12/24 V DC
12/24 V DC
12 V DC
NMEA 2000 NETWORK
SONARHUB
SONARHUB
SPOTLIGHT
HEADING SENSOR
TM150 LSS HD
SPOTLIGHT
TRANSDUCER
CHIRP
and
StructureScan
1
1 2
2
4G RADAR
4G RADAR
MULTI-FUNCTION DISPLAYS
HDS NON-TOUCH
MULTI-FUNCTION DISPLAYS
