7. Function list
7-10
SV-iC5
Function group 2
LED
display
Parameter
name
Min/Max
range
Description
Factory
defaults
Adjustable
during run
Page
H22
2)
[Speed
Search Select]
0/15 This parameter is active to prevent any
possible fault when the inverter outputs its
voltage to the running motor.
0 O 10-
12
1. H20-
[Power
On start]
2.Restart
after
instant
power
failure
3.Operation
after fault
occurred
4.Normal
acceler-
ation
Bit 3 Bit 2 Bit 1 Bit 0
0 - - - -
1 - - -
2 - -
3 - -
4 -
- -
5 -
-
6 -
7 -
8
- - -
9
- -
10
-
-
11
-
12
- -
13
-
14
-
15
H23 [Current level
during Speed
search]
80/200
[%]
This parameter limits the amount of current
during speed search.
The set value is the percentage of the H33-
[Motor rated current].
100 O 10-
12
H24 [P gain during
Speed search]
0/9999 It is the Proportional gain used for Speed
Search PI controller.
100 O
H25 [I gain during
speed search]
0/9999 It is the Integral gain used for Speed search
PI controller.
1000 O
2)
#4.Normal acceleration has first priority. Even though #4 is selected along with other bits, Inverter starts Speed search #4.
