7. Function list
7-11
SV-iC5
Function group 2
LED
display
Parameter
Name
Min/Max
Range
Description
Factory
defaults
Adjustable
during run
Page
H26 [Number of
Auto Restart
try]
0/10 This parameter sets the number of
restart tries after a fault occurs.
Auto Restart is deactivated if the fault
outnumbers the restart tries.
This function is active when [drv] is set
to 1 or 2 {Run/Stop via control terminal}.
Deactivated during active protection
function (OHT, LVT, EXT, HWT etc.)
0 O 10-
15
H27 [Auto Restart
time]
0/60 [sec]
This parameter sets the time between
restart tries.
1.0 O
H30 [Motor type
select]
0.2/2.2 0.2 0.2 kW
-
1)
Automatically
set
X 10-6
0.4 0.4 kW
0.75 0.75 kW
1.5 1.5 kW
2.2 2.2 kW
H31 [Number of
motor poles]
2/12 This setting is displayed via rPM in
drive group.
- X
H32 [Rated slip
frequency]
0/10
[Hz]
×
−=
120
Prpm
ff
rs
Where,
s
f
= Rated slip frequency
r
f
= Rated frequency
= Motor nameplate RPM
= Number of Motor poles
-
2)
Automatically
set
X
H33 [Motor rated
current]
1.0/20
[A]
Enter motor rated current on the
nameplate.
- X
H34 [No Load
Motor
Current]
0.1/12
[A]
Enter the current value detected when
the motor is rotating in rated rpm after the
load connected to the motor shaft is
removed.
Enter the 50% of the rated current
value when it is difficult to measure H34 -
[No Load Motor Current].
- X 10-6
H36 [Motor
efficiency]
50/100
[%]
Enter the motor efficiency (see motor
nameplate).
- X
To Next Page
