INSTALLAZIONE VERTICALE / VERTICAL INSTALLATION / INSTALLATION VERTICALE / AUFSTELLUNG VERTIKAL
INSTALACIÓN VERTICAL /ПОДЪЕМ ВЕРТИКАЛЬНЫЙ
Solo per:
Onlyfor:
Seulement pour:
Nur für:
Solo para:
Только для:
SI-YES-OUI
JA-SI-ДА
NO-NO-NON
NEIN-NO-HET
CONTROVENTATURA
WINDBRACING
CONTEVENTEMENT
WINDVERSTREBUNG
TENSORES CONTROVIENTO
КОНТРГАЙКА
OPTIONAL
Положение крепления
SAL6...V
DRY COOLER
(A, F)(+273*) (B, C, D, L)
(A, F)(+273*) (B, C, D, L)
(A, F)(+273*) (B, C, D, L)
(A, F)(+273*) (B, C, D, L)
(A, F)(+273*) (B, C, D, L)
(A, F)(+273*) (B, C, D, L)
SAL6...V (DRY COOLER)
○○
○○
○○○
○○○
○○○○
○○○○
EAV6...V
SAV7...V
DRY COOLER
EAV5...V
SAV6...V
SAL6...V
EAV5 - SAV6 - EAV6 - SAV7
VERSION GAS COOLER
MOTORI MOTORS MOTEURS
MOTOREN MOTORES МОТОРы
Ø 630
Ø 710
mm x n° 1 2 3 4 5 4 6 8
A mm 1588 2803 4018 5233 6448 2823 4038 5253
EAV6...V Ø 630
SAV7...V Ø 710
B mm 1215 2430 3645 4860 6075 2430 3645 4860
C mm --- --- --- 2430 2430 --- --- 2430
○○
○○
○○○
○○○
○○○○
○○○○
MOTORI MOTORS MOTEURS
MOTOREN MOTORES МОТОРы
Ø 500
Ø 630
mm x n° 1 2 3 4 5 4 6 8
EAV5...V
Ø 500
A mm 1373 2373 3373 4373 5373 2373 3373 4373
SAV6...V
Ø 630
B mm 1000 2000 3000 4000 5000 2000 3000 4000
SAL6...V DRY COOLER
Ø 630
C mm --- --- --- 2000 2000 --- --- 2000
