Installation Instructions
5 | P a g e v 1 . 0 ( 0 7 / 2 0 2 0 )
Safety tips
• Always ensure the power is OFF and the luminaire has cooled down before performing any maintenance, cleaning,
or making any adjustment to the luminaire.
• To avoid injury or damage to the luminaire
, ensure that power leads and screws are secure before connecting the
power.
• The luminaire must not be used if the shades have been cracked. Replace any cracked protective shield.
• The light source of this luminaire is not replaceable; when the light source reaches its end of life, the whole luminaire
shall be replaced.
• Ensure that the luminaire does not come in contact with corrosive chemicals/solvents or abrasive cleaners etc.
• To clean, wipe with a damp clean cloth. Do NOT soak or immerse the product in water or other liquids.
Specifications
SKU # 240915
Colour Black
Rated Voltage 220-240V~ 50Hz
Rated Wattage 20W
LED Specs
1500 lumen, CCT 4000K, CRI > 80, Dimmable via Lucci Connect App*
(* Not suitable with dimmer switch)
IP Rating IP44
Additional Features
(In-app control)
Motion detection notification, Two-way audio, Security camera (Live view & playback),
Buzzer alarm
PIR Sensor spec
Detection range & angle: Max.10M, 180°
Required installation height: 1.8 – 2.5M
Lux & Time adjustment: 0 – 200lux, 10s-10min/3hours/6hours/D2D.
Camera spec
2 Mega (1980*1080) pixel resolution, visual angle 130°
Night vision
Audio spec Two-way audio, speaker 4
Ω
, 3W
Storage card Micro SD card (Max.128G, FAT32)
Security Anti-theft screw for Mounting bracket & SD card slot
Weight 1.0kg
Dimensions H:250mm W:170mm E:210mm
