Beta Draft Confidential
Installing and Removing Modules
Switch Processor Module
CBX 500 Multiservice WAN Switch Hardware Installation Guide 4/5/036-7
8. Check the LEDs on the redundant SP to verify the operational status of the card.
After several minutes, the green Good LED should remain on. Also, the
Redundancy Status LED on the bottom left of the card should be blinking green,
indicating that the card is in standby mode. The active SP’s Redundancy Status
LED should be solid green, indicating that the card is in active mode.
9. Configure the switch for a redundant SP configuration via the NMS software.
For instructions, see the B-STDX, CBX, and GX Switch Module Configuration
Guide.
The Good and Failed LEDs on the newly installed SP blink simultaneously while
the OS software image is being downloaded. This is not an error condition.
Note – If the original operating system (loaded at the factory before shipping the SP)
becomes lost or corrupted, follow the instructions in the appropriate switch-code
release note to download a new OS and configuration.
