NTP-039: Circuit Order 363-206-285
Page 18 of 32 Issue 2, February 2000
DDM-2000 OC-3 MULTIPLEXER
DO ITEMS BELOW IN ORDER LISTED. . . . . FOR DETAILS, GO TO
23.
NOTE:
Wait until FAULT LED on MAIN OLIU extinguishes before
attempting switch.
At Node 1, use the switch-line:main:pri=manual
command to switch service to the protection line (main-2 OLIU
active at Node 1). (See Figure 13.)
Figure 13 – DDM-2000 OC-3 Drop or Add/Drop Network to Ring Upgrade
To Next Page
