Lucent DDM-2000 OC-3 - Page 63

363-206-285 System Turnup/Circuit Order: IXL-001
Issue 3, June 2001 Page 15 of 44
DDM-2000 OC-3 MULTIPLEXER
Figure 6 – DDM-2000/FT-2000 Large Network Configurations — Single-Homed
FiberReach Access via DDM-2000 OC-3 or OC-12 Backbone Ring
Establish Single-Homed FiberReach Access
via DDM-2000 OC-3 or OC-12 Backbone Ring
See Figure 7
Establish Single-Homed FiberReach
Access via DDM-2000 OC-3 or
OC-12 Backbone Ring
[363-206-285 User/Service Manual,
Volume 2 (TOP)]: System Turnup -
NTP-043
