Lucent DDM-2000 OC-3 - Page 71

363-206-285 System Turnup/Circuit Order: IXL-001
Issue 3, June 2001 Page 23 of 44
DDM-2000 OC-3 MULTIPLEXER
Figure 14 – DDM-2000/FT-2000 Large Network Configurations — DDM-2000
OC-12 Path Switched Ring
Establish End-to-End DDM-2000 OC-12 System (OC-12 Shelves)
Path Switch Ring
See Figure 15
