87
GENERAL DATA
ROAD LIGHTING WIRING DIAGRAM
FOG
INDICATOR
STOP
TAIL
REVERSING
(IF FITTED)
FOG
INDICATOR
STOP
TAIL
REVERSING
No PLATE
No PLATE
21w
10w
21w
21w
21w
10w
21w
21w
5w
5w
5w
5w
5w
5w
5w
BROWN 1.0
RED 1.0
GREEN 1.0
BLUE 1.0
WHITE 1.0
YELLOW/BLACK 1.0
WHITE 1.0
BLUE 1.0
YELLOW 1.0
RED 1.0
BLACK 1.0
YELLOW/BLACK 1.0
BLACK 1.0
WHITE 1.0
BROWN 1.0
WHITE 1.0
HIGH LEVEL
STOP LIGHT
N/S REAR MARKER LIGHT
OR SIDE MARKER
O/S REAR MARKER LIGHT
OR SIDE MARKER
PLUG
FRONT MARKER
LIGHTS N/S
FRONT MARKER
LIGHTS O/S
13 PIN PLUG
1
2
3
4
5
6
7
8
9
10
11
12
13
YELLOW
BLUE
WHITE
GREEN
BROWN
RED
BLACK
ORANGE
BLUE/BROWN
RED/BROWN
GREEN/WHITE
EMPTY
BLUE/WHITE
PDU
(IF FITTED)
(IF FITTED)
5w
5w
SIDE MARKER
LIGHTS N/S
SIDE MARKER
LIGHTS O/S
