Lycoming IO-360 Series User Manual

LYCOMING OPERATORS MANUAL SECTION 2
O-360 AND ASSOCIATED MODELS SPECIFICATIONS
DIMENSIONS, INCHES (CONT.)
MODEL HEIGHT WIDTH LENGTH
IO-360 Series (Cont.)
-D1A, -C1D6, -C1G6
-E1A, -F1A, -B1G6
-K2A
, -M1B
19.48
20.70
19.35
20.26
34.25
33.37
34.25
33.38
31.14
32.09
29.81
32.75
AIO-360 Series
-A1A, -A2A
-A1B, -A2B
-B1B
20.76
20.76
20.76
34.25
34.25
34.25
30.08
30.08
30.08
HIO-360 Series
-A1A, -A1B
-B1A
-B1B
-C1A, -C1B
-D1A
-G1A
-E1AD, -A1BD, -F1AD
19.48
19.38
19.38
19.48
19.48
19.68
19.97
35.25
33.37
33.37
34.25
35.25
33.37
34.25
33.65
32.09
30.68
31.14
35.28
31.81
31.36
TIO-360 Series
-A1A
-A1B, -A3B6
-C1A6D
21.43
19.92
21.65
34.25
34.25
19.09
45.41
45.41
35.82
- For information pertaining to engine model (L)IO-360-M1A, refer to Operation and Installation Manual
P/N 60297-36.
Revised March 2009 2-11

Lycoming IO-360 Series Specifications

General

Oil System	Wet Sump
Engine Type	Horizontally Opposed, 4-Cylinder, Air Cooled
Displacement	361 cubic inches (5.9 liters)
Bore	5.125 in (130.2 mm)
Stroke	4.375 inches (111.1 mm)
Cooling System	Air Cooled
