4

Detail Information of Port

4

4.3 ⑫-USB-B (Device)

PIN No.

1

2

Name

VUSB

D-

I/O

P

I/O

Function

+5V

Data -

3

4

D+

GND

I/O

P

Data +

Ground

4.2 ⑪-USB-A (Host)

PIN No.

1

2

Name

VUSB

D-

I/O

P

I/O

Function

+5V

Data -

3

4

D+

GND

I/O

P

Data +

Ground
