SPECIFICATIONS
MODEL 600 ACE
ENGINE
Engine type
Rotax 602, liquid cooled, 4-stroke,
D.O.H.C., dry sump
Cylinders
2
Displacement 600 cm³ (36.6 in³)
Bore 74 mm (2.9 in)
Stroke 69.7 mm (2.74 in)
Maximum horsepower RPM 7250 RPM
Exhaust system Double front pipe, baffle muffler
Engine oil
XPS 4-STROKE SYNTHETIC OIL (F) (P/N 619
590 114)
or SAE 0W 40 API SM synthetic oil
Engine oil capacity Oil change, 2.1 L (2.2 qt (U.S. liq.))
Engine coolant
Ethyl glycol/water mix (50%
coolant, 50% distilled water).
Use LONG LIFE ANTIFREEZE(F) (P/N 619
590 204)
or coolant specifically designed
for aluminum engines
FUEL SYSTEM
Fuel injection system Multi point EFI, 46 mm throttle body
Recommended fuel
Regular unleaded (fuel containing MAXIMUM
10% ethanol)
Minimum octane
rating
RON
95 E10 (fuel which may contain up to
10% MAX ethanol)
Fuel tank capacity 34 L (8.98 U.S. gal.)
ELECTRICAL SYSTEM
Lightning system output 650 Watts @ 6000 RPM
Headlights bulb HI/LOW beam Spark plug 2 x 60/55 Watts (H -4)
Taillight bulb 2 x P 21/5 W
Type NGK MR8BI-8
Spark Plug
Gap .8 mm (.031 in)
______________
133
